Probe Leads Resistance Test

Probe Leads Voltage Test

◆ For P/N 575.0800 AC Analog Clamp Meter

Digital Clamp Meter TM-1015

◆ 3 3/4 digits display with maximum reading of 3999
◆ With auto power-off, data hold, max./min data set
◆ Maximum conductor size 30mm
◆ Dimension: 205 x 64 x 39mm
◆ AC / DC current: 40A, 400A
◆ AC / DC Voltage: 400mV, 4V, 40V, 400V, 600V
◆ Resistance: 400Ω, 4KΩ, 400KΩ, 4MΩ, 40MΩ

[Specifications]:

Overall Length: 225mm
Material: Carbon Steel
Handle Material: TPR
Screw Head Size: Dia. 3~12mm
Removable Screws: Dome (Truss) Head, Round and Pan Head.
Cutting Capacity: Flat Cable dia. 2.6mm x 3 cores / Hard Wire dia. 3.2mm / Copper Wire dia. 4mm / Stainless Wire dia. 2mm / Stranded Wire 8m㎡
Crimping Capacity: Bare Terminals AWG16~12 (1.25~3.5m㎡)
Hardness: HRC 60±2
Weight: 350g

[Features]:

◆ Designed especially for electrician a multi-functional pliers with unique screw extractor.
◆ Eccentric high leverage structure, powerful in cutting and gripping.
◆ 21mm long blade and the specially-designed eccentric structure offer 30% more cutting power compared to conventional pliers.
◆ 2-way non-slip gripping jaw. Vertical serrations grip a screw head securely, while horizontal serrations hold a tie band and a thin plate securely.
◆ The unique T-shaped handle helps prevent the handle sleeve from twisting or turning round and has the feature of light-weight.
◆ Strap hole in the end of the handle prevents the pliers from falling.
