Heater for SK-40.41 Ceramic Soldering Iron Engineer

Polyimide High Temperature Resistant Adhesive Tape Width 5mm

[Specifications]:

Material : Polyimide
Adhesion Type: Silicone
Color : Amber
Width : 5mm
Adhesive Thickness: 0.025mm
Total thickness: 0.055mm
Length : 33M
Elongation: 40%
Temperature Resistance: -73℃ ~ 260℃

[Features]:

◆ Thermal Stability – It can withstand heat and still function well.
◆ Electrical Insulation Properties – Making it the most vital accessory when handling ESD sensitive components in electronics reworking and manufacturing process.
◆ This Polyimide High Temperature Resistant Adhesive Tape has great electrical insulation properties and high temperature resistant.
◆ Wide Applications: protecting gold finger on PCB, soldering tasks, providing shield for electronic components, protecting bed surface and acts as a base layer in 3D printing.
◆ Because it is stable over a wide range of temperature and its feature of electrical insulation, this polyimide tape can protect gold contacts of PCB during wave soldering and hot air leveling process or it can insulate coil at high temperature. In addition to electronics reworking and manufacturing, as 3D printers are more and more prevalent nowadays, this polyimide tape serves as an accountable bed surface material.

For detailed product specifications or other dimensions not listed on our website, please contact our sales team by trading@octopus.com.tw.

Solder Sucker Desoldering Pump SS-02 Engineer

[Specifications]:

Body Material: Aluminum
Surface: Anodized finish with high corrosion resistance
Size: φ20 × 153
Weight: 52g
Cylinder Capacity: 9cc (ml)
Silicone Nozzle: Internal dia. 2mm / External dia. 4mm
Spare Silicone Tube: Inner Dia. 2mm 1pce and 1.5mm 1 pce

[Features]:

◆ Smart mechanish allows easy and continuous operation with one hand.
◆ Designed for sucking up melted solder easily and efficiently.
◆ Self-cleaning shaft makes sure no clogging.
◆ The elastic and heat-resistant silicone nozzle, which withstands contact with a soldering iron 350℃ max, is able to make the solder sucker adhere on board closely.
◆ Suction force is up and the suck-up result is great with less residue.
◆ Spare silicone tube is included for replacement, and you can cut it in desired length.

Replaceable Ceramic Tweezers Curved Tip

[Specifications]:

Shape: Curved Tip
Tip Size: 0.4mm
Overall Length: 125mm
Tip Length: 23mm
Shaft Width: 10mm
Material: Stainless Steel & Ceramic

[Features]:

◆ For precise grasping SMD/SMT components, also great tool for watch and jewelry repair.
◆ Replaceable and changeable white tips made of ceramic are anti-corresive and heat-resistant, while the metal body offers durability and strength for grasping.
◆ Two screws on both sides for you to easily replace the tweezers' tips.

Pb-free Solder Wire Reel 1.0mm 50g

[Specifications]:

Solder Wire Diameter: 1.0mm
Weight: 50g
Application: Copper, Iron, Aluminum, and Stainless Steel.

◆ Lead free.
◆ In reel, for professional users.
